Marine Motor Vane

Marine Motor Vane is mainly used for Crane and Winch Motor. There are 8pcs Marine Vane in the rotor slots. During the operation, Oil Pressure drives the rotor to run together with vanes. Marine Crane and Winch Motor Vanes are suitable for IHI models - HVB, HVN, HVK, HV-LL Marine Motor Vane
Material Hardness Thickness Width Length Radius Precision Surface
Roughness
Alloy Tool Steel
ASTM: 01
JIS: SKS 3
DIN: 100MncrW4 		HRC 58°-62° 7.615 27.000 129.990 Acc.to Drawing ＜5μ Ra＜0.4
7.615 27.000 194.9850 Acc.to Drawing
Spring Steel
ASTM: G61500
JIS: SUP10
DIN: 50CrV4 		HB363-429 7.840 39.500 189.960 Acc.to Drawing ＜10μ
9.840 52.000 319.940 Acc.to Drawing
16.000 100.000 450.000 Acc.to Drawing
